5.08mm pitch female type pluggable screw terminal block with flange ear FPC2.5-XX-508-01

Name: 508mm pitch female type pluggable screw terminal block with flange ear FPC25XX50801
Brand: AOSI
Price: 1 USD

Quality 5.08mm pitch female type pluggable screw terminal block with flange ear FPC2.5-XX-508-01 for sale

Brand Name : AOSI

Model Number : FPC2.5-XX-508-00

Certification : UL CQC CE SGS

Place of Origin : CHINA

MOQ : 100

Payment Terms : L/C, T/T

Delivery Time : 7DAY

Contact Now

MODEL:FPC2.5-XX-508-00
Rated voltage: 300V
Rated current: 16A
Wire range: 28-12AWG(0.5-2.5mm2)
Withstanding voltage: AC2500V/1Min
Ambient temperature: -40°C~+105°C
Strip length: 8.0-9.0mm
Pitch:5.0mm/5.08MM
Poles:2P-24P
Housing:PA66 UL94V-0
Pin header:Cupper alloy
Terminal blocks and strips are insulated connections that fasten two or more wires together and consist of an insulating frame and a clamping system. AOSI's terminal blocks and strips offer a reliable connection with a large variety of technologies and ranges to serve many industrial applications from control to power distribution.

5.08mm pitch female type pluggable screw terminal block with flange ear FPC2.5-XX-508-01

5.08mm pitch female type pluggable screw terminal block with flange ear FPC2.5-XX-508-01 Images
